| ปริมาณการสั่งซื้อขั้นต่ำ: | 1000m |
| ราคา: | USD 0.4 To 30.5 per Meter |
| การบรรจุแบบมาตรฐาน: | กลองเหล็กไม้ |
| ระยะเวลาการจัดส่ง: | 10-15 วัน |
| ความสามารถในการจําหน่าย: | 8KM ต่อวัน |
Solid copper core PVC insulation and sheathing and TC braided shield control cable
1.Product Standards
GB/T 9330.1-2008 GB/T9330.2-2008 GB/T 19666-2005
2.Product use
Laying indoors, cable ditch, pipelines and other requirements of the shielding occasions
3.use characteristics
3.1 The conductor of the cable is the maximum operating temperature of 70.
3.2 Ambient temperature is not less than 0℃
3.3 Cable flame retardant properties meet the requirements of the corresponding indicators in the
GB/T19666-2005 standard.
4.Modle
kvvp1
5.Cable structure size
| Nominal Aluminum(mm2) | Insulation thickness(mm) | shielding copper wire diameter (mm) | sheath thickness (mm) | cable outside diameter(mm) | cable weight(kg/km) |
| 2x0.75 | 0.6 | 0.15 | 1.2 | 8.1 | 94 |
| 2x1 | 0.6 | 0.15 | 1.2 | 8.4 | 101 |
| 2x1.5 | 0.7 | 0.15 | 1.2 | 9.3 | 124 |
| 2x2.5 | 0.8 | 0.15 | 1.2 | 10.5 | 159 |
| 2x4 | 0.8 | 0.20 | 1.2 | 11.7 | 214 |
The above parameters are only part of the parameters, for reference only.
FAQ
A: Yes, we welcome sample order to test and check quality.
A:Sample needs 3-5 days, mass production needs 2-3 weeks .
A: Low MOQ, 1pc for sample checking is available
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
A: Yes, we offer 1 year warranty to our products.
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new cable with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
